item | value |
Condition | New |
Positioning Accuracy (mm) | 0.03mm |
Number of Axes | 2 |
No. of Spindles | Single |
Working Table Size(mm) | 1250×2500 |
Machine Type | CNC Router |
Travel (X Axis)(mm) | 1250mm |
Travel (Y Axis)(mm) | 2500mm |
Repeatability (X/Y/Z) (mm) | 0.03mm |
CNC or Not | CNC |
Place of Origin | China |
Shandong | |
Brand Name | EXCITECH |
Voltage | AC 380/3P/50HZ |
Dimension(L*W*H) | 3.7*2.4*1.7M |
Weight (KG) | 1700 |
Warranty | 12 months |
Key Selling Points | Easy to Operate |
Applicable Industries | Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining, Other, woodworking, cnc machine, wood machine, funiture making |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Warranty of core components | 1 Year |
Core Components | Bearing, Pump, PLC, Other |
Product name | EXCITECH Wooden Cutting Machine CNC Router E2-1530 manufacture |
Working size | 3080*1550*180mm |
Transmission | X Y axis rack and pinion transmission, Z axis ball screw transmission |
Spindle power | 3.0/4.5/6kw |
Motor and driver | Stepper/ Yaskawa |
Controller | Hand-Held Controller |
Spindle speed | 18000r/min |
Table structure | T-slot /Vacuum table |
Rail guide | Japan THK rail guide |
Working speed | 15m/min |
