The EXCITECH Nesting Auto Loading and Unloading CNC Router Machine is designed for high productivity in woodworking and furniture making. It features a working size of 2440*1220*70mm, spindle speed of 24000r/min, and a Yaskawa driving system. With a repeatability of 0.02mm and loading/unloading speed of 15m/min, it ensures precision and efficiency. A carousel tool magazine with 8 slots and X Y rack and pinion drive further enhance its performance.
item | value |
Condition | New |
Positioning Accuracy (mm) | 0.03mm |
Number of Axes | 2 |
No. of Spindles | Single |
Working Table Size(mm) | 1300×2500 |
Machine Type | CNC Router |
Travel (X Axis)(mm) | 1300mm |
Travel (Y Axis)(mm) | 2500mm |
Repeatability (X/Y/Z) (mm) | 0.02mm |
CNC or Not | CNC |
Place of Origin | China |
Shandong | |
Brand Name | Excitech |
Voltage | 50/60V |
Dimension(L*W*H) | 9.16*2.65*2.85M |
Weight (KG) | 1900 |
Warranty | 12 months |
Key Selling Points | High Productivity |
Applicable Industries | Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining, Other, woodworking, cnc machine, wood machine, furniture making |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Warranty of core components | 1 Year |
Core Components | Bearing, Pump, PLC, Other |
Product name | EXCITECH Nesting auto loading and unloading cnc router machine |
Traveling size | 2500*1260*200mm |
Working size | 2440*1220*70mm |
Loading and unloading speed | 15m/min |
Transimission | X Y rack and pinion drive, Z ball screw drive |
Spindle power | 9.6kw |
Spindle speed | 24000r/min |
Working speed | 25m/min |
Tool magazine | Carousel 8 slots |
Driving System | Yaskawa |
