The EXCITECH Full Automatic Edgebanding Machine offers automation, high efficiency, and precision for edge sealing of panel furniture. It features advanced components like a Delta PLC (Taiwan), temperature control module by AUTONICS (Korea), and pneumatic parts from TAIWAN AirTAC and Japan SMC, ensuring reliable performance. With a feed speed of 20-26m min and compatibility with various edge materials (0.4-3mm thickness), it enhances furniture aesthetics while offering waterproofing and durability. Suitable for particleboard, MDF, and wood strips.
Edge banding work is an important process in the manufacture of panel furniture. The quality of the edge banding directly affects the quality, price and grade of the product. By edge banding, it can improve the appearance quality of the furniture, avoid the corners damage and the veneer layer pick up or peel off, and at the same time, it can play the role of waterproofing, close the release of harmful gases and reduce deformation during the transportation and useing process. The raw materials used by the panel furniture manufacturers are mainly for particleboard, MDF and other wood-based panels, the selected edge strips are mainly PVC, polyester, melamine and wood strips. The structure of the edge banding machine mainly includes the fuselage, various processing components and control systems. The processing components mainly include: pre-milling, infrared heating, gluing with quick-melt, rough trimming, fine trimming, corner trimming, scraping, off-cut, spray cleaning agent, buffing with air cyliner controlled. Mainly used for edge sealing of panel furniture. It is characterized by automation, high efficiency, high precision and aesthetics. It has been widely used in panel furniture manufacturers.
| Description | EV681 | ||
| Workpiece length | Min.150mm | Input voltage | 50/60v |
| Working piece width | Min.60mm | Input frequency | 50HZ |
| Workpiece thickness | 10~60mm | Output frequency | 200HZ |
| Edge thickness | 0.4~3mm | Power | 27kw |
| Feed speed | 20~26m/min | Machine size | 10200*1050*1770mm |
| Minimum Workpiece Dimension | 300*80mm or 150mm*150mm | Pre-milling tool | Φ100*H65mm*Φ 30 diamond tool |
| Part’s name | Brand |
| Inverter | Delta( TAIWAN) |
| PLC | Delta( TAIWAN) |
| Human-machine interface | Delta( TAIWAN) |
| Temperature control module | AUTONICS (KOREA) |
| Air switch | DELIXI |
| AC contactor | SHIHLIN (TAIWAN) |
| Intermediate relay | Weidmuller (Germany) |
| Travel switch | America HONEYWELL |
| Switch button | German SIMENS |
| High-speed motor | CHANGLONG( custom) |
| Pneumatic components | TAIWAN AirTAC, Japan SMC |
1.Spray realease agent
This device spray-applies a thin coat of release agent to the upper and lower edge area of the workpiece and prevents squeezed out glue from adhering to the workpiece.
2. Pre-milling unit
It is equipped with diamond tools for better cut and longer use. This device removes the burr or uneveness on the edge of the workpiece, leaving a smooth surface for the edgebanding. It can profile units available upon request.
3. Gluing with quick-melt
The gluing unit features quick melt , reducing the thawing time of glue and guaranteeing perfect glue quality on different edge materials.
4. Corner Trimming
It is equipped with 4 motors and works well with various edge thickness and invariably result in perfect round corner.
5. R scraping
No power scraping mechanism, for PVC/ABS edge banding within 3mm, R scraping edge is to remove the edge of the finishing unit in the processing edge band, so that the edge of the edge band More full and straight.
6. Flat scraping
Pneumatic control, the role is to scrape off the remaining glue left on the wood, reducing the glue line.
Application:
The raw materials used by the panel furniture manufacturers are mainly for particleboard, MDF and other wood-based panels, the selected edge strips are mainly PVC, polyester, melamine and wood strips.
