The Excitech E4 CNC Router features a positioning accuracy of 0.03mm and repeatability of 0.03mm, ensuring precision in woodworking and cabinet making. Equipped with a 9.6KW Italy HSD Spindle, YASKAWA Servo System, and THK guide rails, it delivers high productivity and reliability for industrial use. The machine supports gear transmission, automatic loading unloading, and customizable color options. With a 1-year warranty on core components and comprehensive testing reports provided, it ensures long-term performance and customer satisfaction.
item | value |
Condition | New |
Positioning Accuracy (mm) | 0.03mm |
Number of Axes | 2 |
No. of Spindles | Single |
Working Table Size(mm) | 1500×3000 |
Machine Type | CNC Router |
Travel (X Axis)(mm) | 15000mm |
Travel (Y Axis)(mm) | 15000mm |
Repeatability (X/Y/Z) (mm) | 0.03mm |
CNC or Not | CNC |
Place of Origin | China |
Voltage | 380V/3PH/50HZ |
Dimension(L*W*H) | 9.16*2.65*2.85M |
Warranty | 1 Year |
Key Selling Points | High Productivity |
Applicable Industries | Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining, Other, woodworking, wood machine, cnc machine, furniture making, cabinet |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Warranty of core components | 1 Year |
Core Components | Motor, Gear, PLC, Other, Gearbox |
Product name | Excitech E4 automatic loading/unloading system for CNC router |
motor | YASKAWA Servo System |
Inverter | Taiwan Delta |
Spindle speed | 0-24000r/min |
Spindle | 9.6KW Italy HSD Spindle |
Guide rail | THK |
Application | Kitchen Cabinet Making |
Transmission | Gear Transmission |
Working Voltage | AC 380V/50Hz/3PH |
color | Customer Needing |
